Overview

Kue Pandan Asli is a web-based order management and delivery tracking application for a traditional pandan-flavored cake business operating across three branches: Surabaya, Malang, and Denpasar. The platform unifies order intake, delivery scheduling, courier management, and payment proof handling for three user roles — Admin, Kurir (courier), and Customer/Reseller.

The most distinctive engineering challenge was selling through WhatsApp itself. Rather than sending customers to a website checkout flow, the platform embeds a complete order conversation directly inside WhatsApp — leveraging the Meta WhatsApp Business API (Graph API v24.0) to run a 14-state chatbot that carries customers from "I want to order" all the way to "order confirmed with payment proof uploaded."

The application was deployed to cloud shared hosting — no Node runtime, no VPS, no Docker — which imposed significant build and deployment constraints that shaped the entire delivery workflow.

Key Features

WhatsApp Chatbot Order Flow (OrderBotService)

A full state machine that conducts the entire order conversation inside WhatsApp:

1. INIT → greeting + branch info 2. WELCOMESENT → customer types PESAN (choose category) or PRODUK (browse catalog) 3. MENUSELECTION → interactive list message with categories 4. PRODUCTBROWSING → keyword product search, pesan/menu commands 5. AWAITINGORDERFORM → collects product, recipient, address, date, time 6. AWAITINGDELIVERYMETHOD → 1 = Pick-up · 2 = Grab/GoSend · 3 = Internal Courier 7. AWAITINGLOCATIONORADDRESS → ongkir calculation via DeliveryZoneService 8. AWAITINGDELIVERYSLOT → delivery time slot selection 9. ORDERSUMMARY → summary + total → FIX / BATAL 10. AWAITINGPAYMENTPROOF → receives QRIS payment proof image (SKIP/lewati/nanti allowed) 11. ORDERCONFIRMED → automatic admin notification → CLOSED

Interactive button captions are normalized (e.g. cattumpeng → tumpeng, delivery2 → 2, slotam → AM) so the bot tolerates inconsistent platform payloads.

Multi-Branch WhatsApp Architecture

Each branch owns its own WhatsApp number (regions.metaphonenumberid, nullable additive column). The webhook resolves incoming conversations to the correct branch by metadata.phonenumberid — unknown numbers return HTTP 403. WhatsappMetaService auto-derives the outbound number from the conversation's region, with an optional ?string $phoneNumberId override on every send/typing/mark-as-read method.

Delivery Zone & Ongkir Calculation

DeliveryZoneService estimates distance (Haversine formula) between the branch and delivery address, then calculates shipping cost from a per-region deliveryzones table. Deliveries beyond 14 km are escalated to a human admin (ESCALATEDTOHUMAN state).

Payment Proof Media Handling

IncomingMediaHandler downloads payment receipts (QRIS) and return evidence via the Graph API, compresses images to 60% quality, and stores them under whatsapp-media/payment/ and whatsapp-media/return/. Payment proof handling reuses an existing mediapath when available — preventing duplicate downloads for the same message.

Admin Chat Monitor & Notifications

- Admin Chat Monitor (/admin/chat) — Livewire conversation list, 1:1 manual replies (admin ↔ customer), and per-message delivery status (sent/delivered/read) tracked in whatsappmessagestatuses. - Admin Notifications — order creation and status changes routed to the relevant branch's admin via AdminNotificationRouterService and the adminnotifications table. - Archived conversations — webhook archived tag events archive chats in the admin monitor.

Auth & RBAC

Laravel Jetstream 4 + Fortify + Sanctum handles authentication (including 2FA). Spatie Laravel Permission enforces two primary roles: admin and kurir (courier). Courier-facing pages expose delivery tasks and route management; admin pages cover catalogs, orders, chat, and branch configuration.

Dark Mode UI Overhaul

A full dark-mode remediation pass across the Argon Dashboard interface:

- Replaced invalid custom Tailwind classes (dark:bg-slate-850 → dark:bg-slate-800, dark:shadow-dark-xl → dark:shadow-xl) that were keeping sidebars and forms white in dark mode - Fixed the root "black text on dark mode" bug: dark:text-black / dark:text-bluedark → dark:text-white across page titles and wrappers - Normalized bg-gray-50/text-gray-900 inputs to dark-mode variants with correct placeholder colors - Removed dead CDN assets (403s) — Tailwind, FontAwesome, duplicate Alpine (already bundled by Livewire) — and began building Tailwind locally - Consolidated theme into a single localStorage['theme'] key (reading legacy color-theme), applied pre-paint on `

Notifications & Analytics

Google Tag Manager (GTM-PRXFHTTN) and Google Analytics (G-6GHRM0X2ZS) track public landing-page behavior. Transactional PDFs (invoices, order recaps, courier/customer performance exports) are generated with barryvdh/laravel-dompdf.

Testing

WhatsApp feature coverage includes WebhookVerificationTest, WebhookMessageProcessingTest, OrderBotStateTransitionTest, MultiBranchWebhookTest, AdminChatReplyTest, AdminNotificationsTest, ChatConversationActionsTest, CustomerQuotaTest, and DeliveryZoneServiceTest (unit) — plus standard Jetstream auth tests.

Engineering Decisions

Why WhatsApp is the checkout, not just the channel — Indonesia's SME customers already live in WhatsApp. Building the order flow as a conversational state machine inside WhatsApp (with interactive list messages and image-based payment proof) removed the adoption barrier of a separate checkout funnel while keeping the business's actual payment rail (QRIS) intact.

Per-branch phone numbers over a single number — each branch keeping its own WhatsApp number preserves local customer relationships and lets order routing be inferred directly from metadata.phonenumber_id, rather than forcing every sender to fill in branch context.

State machine over free-form NLP for orders — for high-stakes order capture (product, address, date, total), a structured 14-state conversation guarantees completeness; a human-served escalated fallback covers anything outside the happy path. This is a deliberate contrast to the free-text NLP approach used in my Sakolentra WhatsApp bot — the right tool for each domain.

Impact

The chatbot and admin chat monitor removed the manual back-and-forth of order intake — customers complete the full journey in-chat, admins receive structured order notifications per branch, and couriers work from explicit delivery slots with zone-based ongkir pre-calculated.

Technologies Used

Backend Laravel 10, PHP 8.1+, Laravel Jetstream 4 (Fortify, Sanctum), Spatie Laravel Permission, Laravel Queue, Laravel DomPDF, Guzzle 7

Frontend Livewire 3, Alpine.js, Tailwind CSS 3 (dark mode), jQuery, Argon Dashboard 2, Vite 6 (build committed)

Integrations Meta WhatsApp Business API (Graph API v24.0), QRIS payment proof ingestion, Google Analytics 4, Google Tag Manager

Infrastructure Cloud shared hosting (no Node/VPS), MySQL/MariaDB, Git-based deployment (branch Main-V-1-0-0`)
